Pure Titanium Welded Tube

1. Product introduction: Pure titanium welded tube is an abundant metal in the earth's crust and the ninth industrial metal . Due to its unprecedented strength, lightness, stable market and non-corrosive characteristics, titanium has emerged as the metal of choice fore aerospace ,industry and medical, leisure and consumer products, notably golf clubs and bicycle frames.
2. Payment terms: T/T or L/C.
3. Delivery time: 5-7 days.

Send Inquiry

Description

Product introduction

Pure titanium welded tube is an abundant metal in the earth's crust and the ninth industrial metal . Due to its unprecedented strength, lightness, stable market and non-corrosive characteristics, titanium has emerged as the metal of choice fore aerospace ,industry and medical, leisure and consumer products, notably golf clubs and bicycle frames.

Specification

Name	Titanium welded tube
Standard	ASTM B861 ASTM F137 etc.
Grade	Gr1 Gr2, Gr3, Gr4, Gr7, Gr12 etc.
Size	Cusdomized
MOQ	1KG
Delivery time	5-7 days
Package	Wooden case
Application	Industrial: Pump,Heat exchanger,corrosion resistance device, Bike frame, etc
Certificate	SGS ISO 9001:2008
Color	Sliver
Surface	Pickled, Polished, Sandblasted.

Name	Specification		(mm)	Grade
Titanium tube	Outside diameter	Wall thickness	Tength	Gr1 Gr2 Gr7 Gr9 Gr12
	φ20-φ60	0.6-0.3	≤8000
	φ60-φ108	1.5-5.0	≤6000
Capillaries	φ0.8	0.06	≤300	Gr1 Gr2

Grade	Chemical Composition (<%)
Grade	Ti	AI	V	Fe	C	N	H	O	Other max
Gr1	Blance	---	---	0.2	0.08	0.03	0.01	0.18	0.4
Gr2	Blance	---	---	0.3	0.08	0.03	0.01	0.25	0.4
Gr3	Blance	---	---	0.3	0.08	0.05	0.01	0.35	0.4
Gr4	Blance	---	---	0.5	0.08	0.05	0.01	0.4	0.4
Gr5	Blance	5.5-6.75	3.5-4.5	0.4	0.08	0.05	0.01	0.2	0.4
Gr7	Blance	---	---	0.3	0.08	0.03	0.01	0.25	0.4
Gr9	Blance	2.5-3.5	2.0-3.0	0.25	0.08	0.03	0.01	0.15	0.4
Gr12	Blance	---	---	0.3	0.08	0.03	0.01	0.25	0.4

Product display

Package

Company Information

buy good CNC titanium

About Us

Service

FAQ.

1. How to order?

Please send us your purchase order by Email or call us sales line,or we can make you proforma invoice under your request.

Please provide following detailed information inwhich we need to prepare your order .

1) .Product information -quantity,specification (size,material,technological if needed and packing requirements etc.)

2) .Delivery time required.

3) .Shipping information -company name,street address,phone & Fax number,destination sea port.

4) .Forwarder's contact details,address and company in China .

2. How about the price?

The price is negotiable.it can be changed according to your quantity or package.

When you are making an inquiry,please let us know the quantity you want.

3. How about the sample?

Sample is free,but he airfreight is collect or you pay us the cost in advance.

4. About MOQ?

The MOQ is 1 kg,but for better price you could order more to have more discount.
